Exceptional playback of Compact Disc and high-res audio files
The D-N150 has the same CD transport as LUXMAN’s highly regarded D-380. Carefully auditioned parts include the power transformer, filtering capacitors, Schottky barrier diodes and LUXMAN’s own Oxygen Free Copper (OFC) wire. The Texas Instruments PCM5102A digital-to-analog converter helps deliver a signal-to-noise ratio of 110 dB, presenting music against a background very close to absolute silence.
You can take advantage of the digital-to-analog converter built into the D-N150 to reproduce external sources. Coaxial and optical inputs accept S/PDIF signals up to 192 kHz/24 bits, while the USB input accepts personal computer PCM signals up to 192 kHz/32 bits. The D-N150 is the first LUXMAN product to support Bulk Pet ®* transmission in addition to conventional, isochronous USB transfer. This achieves exceptional sound by reducing the processing load on the DAC. Optical output empowers you to use the D-N150 as a single DAC hub.*Bulk Pet® is a registered trademark of INTERFACE Co.,LTD.
The aluminum remote control feels substantial in your hand. This remote operates not only the D-N150 digital player but also volume on the matching SQ-N150 amplifier.
The D-N150 has compact “A4” footprint, just 210 x 297 mm (8-1/4 x 11-3/4 inches), not including projecting parts. The 5 mm thick aluminum chassis features an elegant, blasted white finish. Hairline finished controls provide a subtle contrast between white and silver.
| Applicable disc | 2channel CD, CD-R |
|---|---|
| Supported sampling frequencies | USB input : 32kHz, 44.1kHz, 48kHz, 88.2kHz 96kHz, 176.4kHz, 192kHz(16, 24, 32bits) COAX/OPT input : 32kHz, 44.1kHz, 48kHz, 88.2kHz 96kHz, 176.4kHz, 192kHz (16, 20, 24bits) |
| Analog output voltage / impedance | 2.1V/300Ω |
| Frequency response | CD :5Hz to 20kHz (+0, -0.5dB) COAX/OPT/USB :5Hz to 50kHz (+0, -3.0dB) |
| Total harmonic distortion | 0.005% |
| S/N ratio (IHF-A) | 110dB |
|---|---|
| Power supply | 230V~(50Hz) / 115V~(60Hz) |
| Power consumption | 13W |
| External dimensions | 297(W) x 98(H) x 222(D) mm 4mm front panel knob of and 8mm rear panel terminals are included in the depth measurement |
| Net weight | 5.0kg(main unit) |
| Accessories | Remote control(RD-27),Power cable |
